HT43 RTJ PRO

Diesel telescopic boom lift

Platform Height: 40.2 m

Key Specs & Features

  • Performance & ease of use
  • Dual load capacity 230 kg – 450 kg
  • Outstanding rough terrain driving features: 4 wheel drive and steer, oscillating axle
  • Up to 4 simultaneous, proportional movements
  • Optimized serviceability
  • Fully modular basket quick and easy to repair
  • Easy access to all components
  • Self-diagnosis tool integrated on the lower control box
  • Best safety feeling
  • Haulotte Activ’Shield™ Bar
  • Smooth and precise controls
  • 2 axis Jib rotation
  • Strong, quick and manoeuvrable boom

Specs Overview

Technical Data
Working height42.2 m
Platform height40.2 m
Horizontal outreach20.2 m
Lift capacity230-450 kg
Platform size2.44 x 0.91 m
Length - stowed14.8 m
Length - storage12.3 m
Width2.5 m
Height - stowed 3.05 m
Height - storage3.05 m
Vertical jib rotation140° (+70°/-70°)
Platform rotation180° (+90°/-90°)
Turntable rotation360° continuous
Tailswing2.8 m
Wheelbase3.5 m
Ground clearance38 cm
Tilt3 °
Drive speed0,3 - 5 km/h
Gradeability40 %
Turning radius - outside 5.74 m
Tires - foam-filled445/65-22.5
EngineTIER 3:PERKINS 55.5 kW (EU) / 62.4 kW (ROW) TIER 4: DEUTZ 55 kW
Weight21 400 kg
Jib length2.45 m
Width - with extended axles3.3 m
EngineDiesel
Horizontal jib rotation150° (+75°/-75°)
Standard Equipment
  • 4 wheel drive and steer
  • Front oscillating axle increasing stability on uneven ground
  • 2 extendables axles
  • Differential wheel lock increasing rough terrain capacity
  • Proportional controls enhancing comfort and safety
  • 4 simultaneous mouvements for highest productivity
  • Dual load capacity 230 kg/500 lbs (2 persons) – 450 kg/990 lbs (3 persons)
  • Common modular large platform with drop bar entry gate
  • Upper control box protection cover and tool tray in plastic ultra-solid
  • Power to platform 110 V / 220 V
  • Safe to use in winds up to 60km/h – 37mph
  • Sound and light alarm for tilt and load
  • Electric pump system and emergency descent
  • 12 V battery / electrical control system
  • Towing hooks
  • Hourmeter
  • Low fuel level indicator (upper control box)
  • Engine pre-heater with light indicator
  • Basket compensation +/-10°
  • Travel alarm
  • Driving beacon
  • Enhanced Swing out engine tray for ease of maintenance
  • Haulotte Activ’Shield™ Bar (for Europe)
  • 2 axis jib rotation
Main Options
  • On-board hydraulic 3.5 kW generator
  • Hydraulic oil cooler
  • Hydraulic oil in tank and circuit for warm countries
  • Biodegradable hydraulic oil
  • Automatic Overspeed Air Shutdown Valve (Electric one-way valve, flame arrestor, spark arrestor)
  • Cold weather kit
  • Air line to platform
  • Cap with key for diesel tank
  • 55 W Platform working light
  • Glazier Pack
  • Pipe cradle pack
  • Lateral swing door gate
  • Haulotte Activ’Shield™ Bar (outside Europe)
  • Welder and Welder support
